(NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED

Send Inquiry

Request To Call Back

(NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED

Price 120000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

(NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED Specification

Weight
50 Kilograms (kg)

Temperature Range
-30 C~+70 C Celsius (oC)

Warranty
1 Year

Product Type
Boom Barrier

Dimension (L*W*H)
976 x 335 x 231mm (HWD) Millimeter (mm)

Connectivity Type
Wired/remote

Color
White & Grey

License Free
Yes

Size
340mm * 272mm * 1020mm (L*W*H)

Mounting Type
Surface mount

Operating Mode
Automatic/manual

Technology
Ultra Fast Electro Mechanical

Special Features
LED strip on Boom, IP544 Waterproof

Remote Control
Yse

Application
Toll Plaza, Traffic Barrier

Power Supply
220V, 150W

Suitable For
Outdoor use

Protective Cover
Yes

LED Boom Lighting
Integrated

Boom Material
Aluminium with LED

Body Material
Stainless steel

Base Color
Black

Barrier Arm Length
3 to 6 meters

Duty Cycle
100% Continuous

Model
NS-BS2-P63D01L

Operation Speed
1.5-3 seconds

Weather Resistance
Excellent

Control Interface
Dry contact

(NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About (NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED

ULTRA FAST ELECTROMECHANICAL BOOM BARRIER (WITH LED TRAFFIC LIGHT)

Boom Length: Upto 6 meter

Boom Type- Straight Arm/Telescopic Arm

Open/close Speed: 0.8 Within 3mtr, 1.5s Within 4.5mtr, 2 to 6s Within 6mtr

Motor Power: 160W

Driving Method: DC Brushless Motor

Torque: 56.8N.m

Power failure Action: Auto Open

Arm swing-out function: Yes

Protection Grade: IP54

MCBF: 10 + Million

Traffic Indication

Advanced Technology for Fast Access Control

The NS-BS2-P63D01L barrier utilizes ultra fast electro mechanical technology, facilitating exceptional operation speed (1.5-3 seconds). Designed for professional environments, it handles continuous duty cycles and seamless access control, making it an excellent solution for managing vehicle flow at locations such as toll plazas, commercial gates, or busy parking areas.

Robust Construction and Weather Protection

Crafted with a stainless steel body and aluminium LED-illuminated boom, this barrier is engineered for durability. Enhanced weather resistance and an IP544 waterproof rating allow it to perform reliably outdoors in harsh climates, while its protective cover offers further safeguarding of internal components.

Intuitive Operation and Versatility

With options for both automatic and manual use, as well as support for wired and remote connectivity, the NS-BS2-P63D01L suits various operational preferences and scenarios. Its dry contact control interface ensures easy integration with existing security infrastructure, while surface mounting makes installation straightforward.

FAQ's of (NS-BS2-P63D01L) Ultra Fast Electro Mechanical Boom Barrier with LED:

Q: How is the NS-BS2-P63D01L boom barrier controlled and operated?

A: This model supports both wired and remote control operations, providing options for automatic or manual use. Its dry contact interface allows integration with diverse access control systems.

Q: What are the main benefits of the integrated LED strip on the boom?

A: The built-in LED strip enhances visibility in low-light or adverse weather conditions, increasing safety and clearly indicating barrier position to drivers, especially at night or during rain.

Q: Where is the NS-BS2-P63D01L boom barrier typically installed?

A: It's primarily designed for outdoor applications such as toll plazas, traffic control points, commercial entry gates, and parking areas, thanks to its robust construction and weatherproof features.

Q: What makes this boom barrier suitable for continuous, heavy-duty use?

A: It features a 100% continuous duty cycle mechanism, supported by durable materials, ultra fast operation speed, and excellent weather resistance so it can function reliably in high-traffic zones throughout the year.

Q: What is the process for installing the boom barrier?

A: Installation involves surface mounting the unit and connecting power (220V, 150W). The device's standard wiring and control interface facilitate straightforward integration into new or existing access control setups.

Q: When should the boom barrier's manual operation be used?

A: Manual mode is useful during power outages or when maintenance work is required, providing uninterrupted security and control even if automatic systems are temporarily disabled.

Q: What warranty and support are provided with the product?

A: The NS-BS2-P63D01L comes with a 1-year warranty. As an exporter, manufacturer, service provider, and supplier in India, the company offers comprehensive customer support and after-sales service.
